Once connected to the system, the interface remains consistent whether using a matrix or any version of the AV over IP solution. In this example, an IP device has been reset. If this were a matrix, the inputs and outputs would be preset (e.g., input 1, 2, 3, 4 and output 1, 2, 3, 4). However, with AV over IP, there is an additional step to scan and assign all input and output devices to the controller. The system automatically searches the network and detects devices. One of Netvio’s key advantages is its pre-configured network switches. Typically, configuring network switches for multicast and IGMP snooping requires at least an hour of training, along with specific settings for various switch brands. Training on one brand, such as Cisco, would not apply to others like Netgear or Juniper, requiring extensive documentation and configuration guides. Instead, Netvio offers a streamlined solution with pre-configured 24-port and 48-port switches. These plug-and-play switches simplify deployment for systems with up to 20 or 45 devices. They are clearly labeled for connecting controllers, encoders, decoders, and Wi-Fi networks, ensuring seamless configuration and control. Once all devices synchronize with the controller, the system applies a preset configuration to each unit, restoring them to factory defaults. Initially, the discovered devices appear as red icons. During synchronization, the icons change to indicate progress. Once complete, a blue RJ45 icon confirms successful synchronization. If an issue arises, the icons may turn red, signaling a network configuration problem. At that stage, reviewing the switch settings would be necessary. Using a Netvio switch, video can be routed across the network within seconds. Expanding any input reveals a preview stream, providing a real-time snapshot of each source. This feature is particularly useful during initial setup, allowing easy identification and labeling of sources. Instead of referring to a device by its MAC address or model number, sources can be named intuitively, such as "Apple TV" or "Media Player." This preview function also serves as a troubleshooting tool. If network issues are present, corrupted video may appear in the preview window, indicating that the HDMI connection at the source is fine, but there is a network-related issue preventing proper video transmission. For technical support, remote access to this screen provides a wealth of diagnostic information, streamlining troubleshooting. Key details such as resolution, encoder format, EDID settings, and IP validity are displayed. Enabling audio information reveals source audio type and even the Dante IP address of the device. Although the IP address may not yet be valid in this demonstration, it can be configured shortly. The extensive two-way feedback and diagnostic data provided by Netvio surpass many other AV over IP solutions. Simply accessing this screen remotely allows technicians to identify and resolve most issues quickly. Finally, outputs can be labeled for organization, which will be useful later in the setup process. Devices can be reordered using arrows or by dragging them into place. This organization is particularly beneficial during control system configuration, as grouping adjacent screens simplifies programming and enhances workflow efficiency.
