IP-JP4-60-DNT-TX-10
4K60 (4:4:4) AVoIP Dual Stream Encoder over 1GbE up to 100m (328ft) with Dante AV-A
-
Newest iteration of Dante compatible video solutions.
-
Adds two channels of Dante audio that are interoperable with any Dante-enabled device.
-
Device monitoring through Dante Director & Domain Manager.
-
Latest Gen2 Dual 1Gb 4K (4:4:4) HDR, 2K30 PoE Encoder
-
Superior picture quality with pixel-for-pixel quality,
-
4K HDR video encoding not surpassing 850Mbs
-
ContentPlus+ 2K30 Low Bandwidth Real-time-stream-protocol (RTSP) including stereo audio
-
Fast Switching with Genlock Synchronicity.
.png)
.png)
.png)
Dante AV-A extends Audinate’s world-leading audio networking into video, creating one unified platform for distributing both over standard IP networks. This removes the need for separate cabling systems, simplifies design, and lowers overall costs.
Supporting 4K60 4:4:4 video with sub-frame latency and HDCP-protected content, Dante AV-A delivers cinema-quality performance on gigabit Ethernet. With seamless integration into the vast Dante ecosystem, it enables scalable, flexible, and future-proof AV systems that meet the demands of modern installations.
Products that have just Dante carry audio-over-IP only. They let you move multichannel audio across a network with precision, low latency, and wide interoperability — but video still has to be handled separately (HDMI, HDBaseT, Standard AVoIP, etc.).
Dante AV-A, on the other hand, adds video transport into the same Dante ecosystem. That means both audio and video can be distributed, synchronized, and controlled on a single IP network with one management platform. It eliminates the split infrastructure and gives installers true end-to-end AV-over-IP within the same workflow.
👉 In short: Dante = audio only. Dante AV-A = audio + video together, unified and synchronized.
Netvio’s two-mode approach to Dante AV-A delivers both openness and optimization.
In Native Mode, Netvio endpoints operate as standard Dante AV-A devices, streaming audio and video with full interoperability across the wider Dante ecosystem. This ensures compatibility with other manufacturers’ Dante-enabled products and is ideal for enterprise-scale, mixed-brand installations.
In Enhanced Mode, Dante AV-A is optimized within the Netvio ecosystem. This unlocks advanced features such as ContentPlus+ dual-stream RTSP, simplified configuration through Netvio360, and seamless end-user control via NetvioGo. Installers benefit from the same low-latency, pixel-perfect video performance while gaining extra functionality and faster deployment.
In Netvio Enhanced Mode, installers should use Netvio’s own IP-SW Series switches, which are fully preconfigured for plug-and-play performance with up to around 45 devices. These deliver multicast, PoE, and ContentPlus+ support straight out of the box, making them the fastest way to deploy Netvio AVoIP.
For larger systems over 45 devices or when running in full Dante AV-A Mode, Netvio recommends moving to approved enterprise-grade switches from Netgear or Cisco. These models meet Audinate’s Dante AV-A requirements for IGMP, jumbo frames, and QoS, ensuring reliability and interoperability across the wider Dante ecosystem.
No — you don’t need the IP-JP4-CL-10 controller when running in Dante AV-A mode. In this mode, devices are discovered and managed through Audinate’s Dante Controller and Dante Domain Manager, just like other Dante products.
The controller is only required in Netvio Enhanced Mode, where it provides centralized setup, management, and advanced features such as ContentPlus+ streaming, Netvio360 configuration, and NetvioGo control integration.
👉 In short: Dante AV-A Mode = managed with Dante Controller, no Netvio CL needed. Netvio Mode = CL-10 required for Netvio’s ecosystem features.
In Netvio Mode, you can use all the standard Netvio drivers compatible across the entire Netvio product range, as well as enjoy seamless integration with Netvio360, NetvioGo, and AppBuilder for configuration and end-user control.
In Dante AV-A Mode, control is handled through third-party platforms, with official drivers for Crestron, Q-SYS, and AMX available for download. A full Dante AV-A API document is also available upon request, enabling deeper integration into enterprise-class AV systems.
Netvio provides a simple utility software, available as a free download, to configure the AV settings of encoders and decoders. In Netvio Mode, devices are then discovered and managed through Netvio360, with seamless integration to NetvioGo and AppBuilder. In Dante AV-A Mode, devices are managed using Audinate’s Dante Controller, with Dante Domain Manager available for advanced configuration.
Yes — but not with Netvio360. Dante AV-A devices are controlled and monitored through Audinate’s Dante Domain Manager, which supports secure remote access and monitoring via the cloud. This allows integrators and IT managers to manage Dante AV-A endpoints, user permissions, and system health from anywhere.
👉 In short: Netvio360 covers Netvio Mode. For Dante AV-A Mode, cloud control/monitoring is handled through Audinate’s Dante Domain Manager.
Dante AV-A
4K60 4:4:4 video quality delivers pixel-for-pixel perfection, with every pixel carrying full color data at a smooth 60 frames per second.
This ensures sharper text, vibrant colors, and lifelike motion—essential for control rooms, video walls, high-end home cinema, and immersive presentations, and increasingly critical with larger displays
One Product, Two Opportunities
Netvio's JP4-60-DNT encoders and decoders have multi-modes according to project requirements. Deployed as a part of smaller Netvio managed solution or cloud managed by the latest Dante AV-A software and tools, the JP4-60-DNT series is a versatile product fully licensed out of the box.
Netvio Mode
Netvio Mode is an extension to a conventional AVoIP project, adding JP-DNT devices to enable Dante streaming capabilities. System configuration is managed by Netvio360, with encoder & decoder control using IP-JP4-CL-10.
AV-A Mode
AV-A is the newest video management platform by Dante. In contrast to Netvio Mode, Dante AV-A is managed and controlled exclusively by familar Audinate software tools including Controller, Domain Manager where value add features such as remote access are inclusive.
Netvio Mode
-
Free Netvio Software Configuration
-
Dante Audio
-
Subscription Free
-
Requires IP-JP4-CL-10 Controller
-
Compatible with NetvioGo
-
Control System drivers for Crestron, Q-SYS, Control4, Savant, Elan, RTI
-
Compatible with Netvio SW-IP & 3rd Party Network Switches.
-
Compatible with Netvio ContentPlus+ Secondary 2K streaming.
AV-A Mode
-
Configured using Dante software tools.
-
Controlled using free Dante Controller
-
Compatible with Dante Director (subject to subscription).
-
Does not require IP-JP4-CL-10 Controller
-
Control System drivers for Crestron, Q-SYS & AMX
-
Compatible with third-party network switches only.
-
Compatible with Netvio ContentPlus+ Secondary 2K streaming.
Secure Your Dante Network
Add Netvio devices to Dante Director to enable user authentication for device access, control and management. Only authorized users can connect, modify device subscriptions and monitor media flow.
Remote Management
Remotely launch Dante Controller to manage, update and reconfigure your Netvio Dante Device subscriptions. No more need to physically plug laptops into the local network to access and configure device subscriptions and routing.
Remote Control
Manage your network and monitor the status of your Netvio devices from any location with any web browser. Monitor Dante device clocking, connectivity, and latency for one or more physical IP networks from a convenient online dashboard.
AV over Routed Networks
Dante Director gives you the ability to route Netvio across subnets barriers, giving you the flexibility to configure logical AV pathways and subscriptions to meet your needs. Extend your Dante network beyond the limitations endemic to unmanaged network configurations.
Integrator Friendly
Manage and monitor multiple discrete customer networks from any remote location with your web browser, requiring fewer onsite visits to resolve customer issues. All customer accounts can be managed from a single account, providing a convenient managed service dashboard for daily use.
Event Logging
Dig deep into potential issues with detailed device event logging provided for each discrete device connection.
.png)
.png)
.png)
Dante Certification Level 1
3.0 CTS, CTS-D or CTS-I RUs
1.5 CEDIA CEUs
Dante Certification Level 1 provides an introduction to the Dante platform. It offers fundamental knowledge on digital audio, digital video, basic network and how to setup a basic Dante network using Dante Controller. This course provides enough knowledge to operate a Dante system in daisy chain mode or on a single network switch.
Dante Certification Level 2
3.0 CTS, CTS-D or CTS-I RUs
1.5 CEDIA CEUs
Dante Certification Level 2 offers a deeper explanation of how to create larger networks. This class offers insights on how much bandwidth is used, how to manage it, basic optimization and factors if you wish to chase an external clock. Level 2 is helpful when working on systems that will involve multiple network switches.
