EX-HT2-USB2-0201-10

4K60 4:4:4 HDMI & USB-C Extender with USB 2.0 KVM to 70m (231ft).

Flexible inputs – Switch between HDMI or USB-C at the transmitter for maximum BYOD compatibility.
Uncompressed 4K60 4:4:4 video – HDMI 2.0b with HDR10, Dolby Vision, and HLG pass-through.
USB 2.0 KVM extension – Supports webcams, touch panels, storage devices, keyboards, and mice.
70 m extension – Reliable long-distance transmission over Cat6/6A cabling.
Audio de-embedding – Analog L/R audio output for tie-in to amplifiers or PA systems.
Control pass-through – Bi-directional IR and RS-232 for integration with control systems.
PoC simplicity – Power from either transmitter or receiver using the included PSU.
Installer-friendly – Plug-and-play design with EDID management and compact metal housings.

Video & Audio

Max Resolution: 4K@60Hz 4:4:4 (HDMI 2.0b, 18Gbps)
HDR Support: HDR10, HDR10+, Dolby Vision, HLG
Audio (HDMI/USB-C/HDBT): LPCM 2/5.1/7.1, Dolby Digital/Plus/EX, Dolby TrueHD, DTS, DSD
Analog Audio Output: LPCM 2CH (3.5mm stereo)

Transmission Distances

Standard Mode: Up to 100m (328ft) — 4K60/4K30/1080p
Long Reach Mode: Up to 150m (492ft) — 1080p 8-bit
HDMI Cable Limits: 4K60 — 12m (39ft), 4K24 — 15m (50ft)

USB

USB 2.0 compliant
TX: 1x USB Host (Type-B), 3x USB Device (Type-A, 500mA each)
RX: 2x USB Device (Type-A, 1000mA each).

What's In The Box

1 × EX-HT2-USB2-0201-10 Transmitter (TX)
1 × EX-HT2-USB2-0201-10 Receiver (RX)
1 × IR Blaster Cable — 1.5m (4.9ft)
1 × IR Wideband Receiver Cable — 1.5m (4.9ft)
2 × 3-pin Phoenix Connectors (male)
4 × Mounting Ears
8 × KM3×4 Machine Screws
1 × 24V/3.75A Desktop Power Supply
1 × User Information

Control

RS-232 pass-through (3-pin Phoenix)
Bi-directional IR (20–60KHz)
EDID management
API control via RS-232 or micro USB

Power

Supply: 24V DC, 3.75A (US/EU plug, CE/FCC/UL)
Consumption: Max 97.92W (with 60W USB-C charging + PoC)
PoC: Bi-directional 24V

Mechanical

TX Size: 170×102×22mm (6.69×4.02×0.87in) — 491g (1.08lb)
RX Size: 144×78×23mm (5.67×3.07×0.91in) — 334g (0.74lb)
Metal enclosure, black finish

Environmental

Operating Temp: 0°C–40°C (32°F–104°F)
Storage Temp: -20°C–60°C (-4°F–140°F)
Humidity: 20–90% RH (non-condensing)

EX-HT2-USB2-0201-10

4K60 4:4:4 HDMI & USB-C Extender with USB 2.0 KVM to 70m (231ft).

The Netvio EX-HT2-USB2-0201-10 is a professional HDBaseT 2.0 extender designed to deliver uncompressed 4K60 4:4:4 video, USB 2.0 pass-through, and flexible HDMI/USB-C input switching up to 70 m (230 ft.) over a single Cat6/6A cable.

With full support for HDR10, Dolby Vision, and HLG, plus integrated USB KVM functionality, it provides seamless connectivity for laptops, peripherals, cameras, and interactive displays.

Additional features such as audio de-embedding, bi-directional IR and RS-232 control, and PoC (Power over Cable) make it an installer-friendly solution for modern collaboration, education, and enterprise AV applications.

70m (231ft)

4K60 4:4:4

USB2.0 KVM

PoC

HDMI & USB-C

Cat5e or Cat6 cabling is typically sufficient for most signal transmissions. However, for higher resolutions over longer distances, Cat6a is recommended to ensure optimal performance.

⚠️ Note: Pre-made patch cables using stranded copper (common in consumer-grade products) may not achieve the advertised transmission distances. For optimal performance, use solid copper cables typically found in professional installations.
Contact Sales
Yes. It supports USB 2.0 extension for devices like cameras, drives, keyboards, and touchscreens as KVM, while providing continuous video connections via HDMI or USB-C.
Contact Sales
Yes. When the TX is powered, the USB-C port can deliver up to 60W to connected devices.
Contact Sales
Up to 4K60 4:4:4 with HDR10, HDR10+, Dolby Vision, and HLG pass-through.
Contact Sales
Yes. Both TX and RX have stereo analog audio outputs (3.5mm) for de-embedding from HDMI/USB-C.
Contact Sales
No. Bi-directional 24V PoC allows powering from either the TX or RX with the supplied 24V/3.75A adapter.
Contact Sales
Yes. Control via RS-232 or the SERVICE (Micro-USB) port using ASCII commands (115200, 8-N-1, CR/LF). You can switch inputs, set autoswitch mode, toggle downscaling, mute audio, manage EDID, lock buttons, and reboot. API Documentation is provided below,

Plug & Play Meeting Room

Name: Netvio EX-HT2-701-10 HDBaseT Extender
Brand: Netvio
SKU: EX-HT2-701-10
Price: 458.00 GBP
Availability: InStock

The Netvio EX-HT2-USB2-0201-10 is designed with true plug-and-play simplicity, eliminating the need for complex setup or drivers. Its dual switching input allows users to effortlessly toggle between HDMI and USB-C sources, making it easy to connect laptops, PCs, or other devices in seconds.

With automatic detection and seamless switching, the extender ensures uninterrupted performance and a hassle-free experience, perfectly suited for meeting rooms, classrooms, and collaborative environments where speed and reliability matter most.
