EX-HT3-4001-10
HDBaseT 3.0 HDMI Extender with eARC/ARC (40m 4K, 70m 1080p)
-
Powered by HDBaseT 3.0 – uncompressed 4K60 4:4:4, zero-latency video
-
HDR compatibility – HDR10, HDR10+, Dolby Vision, HLG
-
eARC/ARC audio return – Dolby Atmos, Dolby TrueHD, DTS-HD Master Audio
-
HDMI 2.0b, HDCP 2.2/2.3 compliant for full UHD content support
-
Transmission distance: 4K up to 40 m, 1080p up to 70 m over Cat6/6a
-
Audio embedding/de-embedding via L/R and SPDIF ports
-
Bi-directional IR, RS-232 & CEC passthrough for complete system integration
-
Compact, durable metal housing with professional mounting accessories
.png)
4K60 4:4:4
eARC
Dolby Atmos
DTS:X
HDBaseT 3.0
Why HDBaseT3?
HDBaseT 3.0 is the next step beyond HDBaseT 2.0, designed to meet the increasing demands of modern video distribution.
While HDBaseT 2.0 can carry 4K60 4:4:4 content using light compression, HDBaseT 3.0 delivers the same resolution completely uncompressed, ensuring pixel-for-pixel image integrity with full HDMI 2.0 support, including HDR.
In addition, it introduces eARC functionality, allowing delivery of advanced audio formats such as Dolby Atmos for truly immersive experiences. Together, these improvements make HDBaseT 3.0 a more future-ready platform for high-end displays, LED walls, and premium home cinema installations.
.png)
.png)
.png)
HDBaseT 2.0 required compression for 4K60 4:4:4 signals, but HDBaseT 3.0 supports the full 18 Gbps HDMI 2.0b bandwidth uncompressed. This means the video is pixel-for-pixel identical to the source, ensuring ultimate picture fidelity. HDBaseT 3.0 also provides robust support for eARC, control, and multiple audio formats, making it the most reliable one-cable solution for today’s AV systems.
The EX-HT3-4001-10 transmits uncompressed 4K60 4:4:4 video with HDR up to 40m (131ft) over a single Cat6/6A/7 cable. This ensures flawless UHD performance across large residential or commercial spaces.
ARC (Audio Return Channel) supports compressed formats such as Dolby Digital 5.1, while eARC (Enhanced ARC) provides the bandwidth for lossless Dolby TrueHD, DTS-HD Master Audio, and Dolby Atmos. With support for both ARC and eARC, the EX-HT3-4001-10 ensures full compatibility with modern displays, AVRs, and soundbars.
Yes. The L/R IN/OUT port allows installers to embed external analog audio into the HDMI signal or extract audio from the HDMI input for routing into analog amplifiers or distributed audio systems.
The extender handles LPCM, Dolby Digital/Plus/TrueHD, DTS, DTS-HD Master Audio, and DSD, with SPDIF supporting up to Dolby Digital 5.1 and DTS 5.1. This ensures compatibility across cinema-grade and distributed audio setups.
Yes. It passes HDR10, HDR10+, Dolby Vision, and HLG, maintaining full dynamic range and color depth from UHD Blu-ray, streaming, or media players.
With bi-directional Power over Cable (PoC), only one unit (TX or RX) needs to be connected to the included 24 V PSU. Power is delivered across the Cat6/6A link to the other unit, simplifying installation and reducing cable clutter.
